Frosted Visualization Strip for Glass Panes 5cm
From

delivery at 4,90 € estimated on 10/10

Configure product

Complies with safety standards concerning the visibility of glass walls.


Select size

Select quantity

1
5
10

Custom quantity

Congratulations! You've arrived!
Unit price:

Need help ?

Can't find what you're looking for?

Our team can make you a customized offer and work out a solution together.

Total:
Unit price:
If the length exceeds 2 meters, the frosted film will be cut into several sections to facilitate installation.

Product help

Downloadable documents

Installation instructions

Frosted Viewing Strips for Glass Panes 5cm

Choose a 5cm wide frosted visualization strip for glass walls. According to the laws of the Voirie et Espaces Publics sector, their use is made compulsory by the decree of August 1, 2006, supplemented by the DGUHC 2007-53 circular of November 30: “Doors (or partitions) with a significant glazed area must be identifiable by visual elements. It is recommended to place the motifs inside 2 horizontal strips 5 cm wide, located at 1.10 m and 1.60 m high”.

The visual strip can be used to mark glazing and partitions in public areas. Ideal for government and corporate buildings, town halls, shops, waiting rooms, hospitals, banks, etc.

The benefits of viewing strips

  • Highlight glazing
  • Complies with safety standards concerning the visibility of glazed walls, in accordance with the decree of August 1, 2006
  • Compatible with all types of glazing
  • Easy to install

The product is delivered in 2m pieces for easy installation.

Technical data



Material PVC polymer
 manufacturing process Calandered
material PVC
service life 8 years
Resistance Indoor and outdoor
Thickness 80 µm
Application surface Flat
Substrates  Glass, metal, varnished wood, paint, some rigid plastics, aluminum, metal, acrylic,
Application temperature 10°C à 30°C
Temperature resistance -40°C à +90°C
Application limits
  • Wavy or highly irregular surfaces, or with features such as large rivets or bolt heads
  • Substrates that do not have a clean, smooth surface, or poor cohesion between paint and substrate
  • Stainless steel
  • Flexible substrates
  • Three-dimensional surfaces

Instructions for use

Substrate preparation

All surfaces, including freshly painted ones, must be cleaned before applying adhesive film.

Do not use greasy solvents such as methylated spirits.

Application

Check substrate temperature, which must be between 10°C and 30°C, and humidity below 80%.

Dry installation.

Care

Always wait one week after application before cleaning the marking.

Use the same type of cleaning product as for high-quality painted surfaces. The product should be liquid, non-abrasive, free from aggressive solvents, and have a pH between 3 and 11 (neither too acidic nor too alkaline).

High-pressure cleaning must comply with certain rules:

  • Maximum pressure 80 bar
  • Maximum temperature 25°C
  • Do not position the nozzle less than 30 cm from the surface, and 60 cm from welds
  • Keep the jet perpendicular to the surface, without insisting on the edges.

Removal

The film has a permanent adhesive, making it difficult to remove.

The use of a heat generator can facilitate film removal.

Any residues can be removed with rubbing alcohol, which is strong enough to remove the adhesive without attacking the substrate.
